Copper Tube Square Cheap 99% Pure Copper Nickel Pipe 20mm 25mm Copper Tubes 3/8 Brass Tube Pipe

Copper pipes are commonly used in the construction industry for residential water supply lines and sometimes for drain and vent lines. Copper pipes can be manufactured as soft or rigid copper and they offer excellent corrosion resistance and reliable connections. While flexible PEX (cross-linked polyethylene) is now the more common choice for new installation and upgrades, copper pipe still has its place.

It is considered a sturdier building material that has a longer lifespan—lasting up to 70 years. However, copper is about 60 percent more expensive than PEX, and it can be susceptible to cracking if the water inside the pipes is subject to freezing temperatures.

The three most common types of copper pipe used in residential and commercial construction are Type K, Type L, and Type M. A fourth type, used for drain-waste-vent, or DWV, piping, is found most often in some older homes. Below, we'll discuss how to choose the right copper pipe for your application.

GB	ISO	ASTM	JIS
TU1	Cu-OF	C10200	C1020
T2	Cu-RTP	C11000	C1100
TP1	Cu-DLP	C12000	C1201
TP2	Cu-DHP	C12200	C1220

GB	Composition(%)
	Cu	P	O	Other
TU1	99.97	0.002	less than 0.002	balance
T2	99.9	-	-	balance
TP1	99.9	0.004-0.012	-	balance
TP2	99.9	0.015-0.040	-	balance

ASTM	Composition(%)
	Cu	P	O	Other
C10200	99.95	0.001-0.005	-	balance
C11000	99.9	-	-	balance
C12000	99.9	0.004-0.012	-	balance
C12200	99.9	0.015-0.040	-	balance

Grade		Temper	Thickness /mm	Elongation A11.2/%	Hardness
					Thickness/mm	HV
T2 TP1 TP2 TU1	C1100 C1201 C1220 C1020	M20	4- 14	no less than 30	-	-
		060	0.3-10	no less than 30	noless than 0.3	no more than 70
		H01		no less than 25		60-95
		H02		no less than 8		80-110
		H04		-		90-120
		H06		-		no less than 110

item	value
Type	Straight Copper Pipe
Application	Water Tube
Specification	0.3-3.0mm
Grade	Brass/Copper
Length	200/300/400/500/600
Cu (Min)	99.9%
Alloy Or Not	Non-Alloy
Ultimate Strength (≥ MPa)	980
Elongation (≥ %)	110
Wall Thickness	standard
Outside Diameter	0.3-3.0
Processing Service	Bending, Decoiling, Welding, Punching, Cutting
Product Name	Copper Tube
Standard	JIS ASTM DIN EN ISO
Material	C10200/C11000/C12000/C12200/TU1/TU2/T2
Shape	Round Roll
Usages	Decoration
Hardness	1/2hard 1/4hard Soft

Jiangsu Hengsai Metal Materials Import and Export Co., Ltd. is located in Wuxi City, a beautiful city near Shanghai. Wuxi is close to Shanghai (BAO STEEL) ,Zhangjiagang (ZPSS),Ningbo (BAO XIN),KUN SHAN (DKSS), enjoy excellent geographic location and convenient water, land and air transportation. , Wuxi become the biggest stainless steel sheet ,plate and coil supply Centers in China.Jiangsu Hengsai Metal Materials Import and Export Co., Ltd. was established in 2009 years. as one of the largest stockists and manufacturers of industrial grade Stainless Steel products and derivatives in Wuxi ,We keep a stock of 50000 tons every month, so we can delivery goods in fast time.
